Key Features
• High efficiency hot water unit
• Satisfies the residents’ daily demand for hot water in big house (bath, shower, laundry, washing, underfloor heating, etc.)
• R410A, probably the most preferred refrigerant at the present time, easy to maintain and commonly used
• Safe and environment friendly
• Energy-saving, uses renewable energy source (outside air), and reduces electricity heating costs by 50-80%
• the cost even more economical, if solar heating is added
• Reduces carbon emissions by offsetting electricity usage
• Simple to install
• Works all day and not affected by the severe weather
• Compatible with connection to a solar thermal collector
Specifications
Performance Parameters* | WBK16AR5N |
Rated heating capacity (kW) | 16 |
Rated power input (kW) | 3.64 |
COP | 4.40 |
Hot water temperature range | 20～55℃ (Adjustable) |
Applicable ambient temperature | -7～43℃ |
Rated hot water capacity (L/h) | 345 |
Circulating water flow (m³/h) | 2.76 |
Power supply | 1Φ/220V/50Hz |
Compressor type | Flexible scroll
|
Nominal current (A) | 19.47 |
Max current (A) | 29.20 |
Refrigerant | R410A |
Water resistance | <80kPa |
Noise level dB (A) | 58 |
Water pipe interface | DN25 |
Net dimensions (mm) | 955×355×1250 |
Box dimensions (mm) | 1110×375×1350 |
* The specifications above need to be calibrated by experiments.
